They are widely used not only by structural design engineers but also by engineers working with thin-walled bodies and truss-like structures. SpaceClaim is a great solution for simplifying CAD geometries especially in case of beams and shell models. A typical example of this is the conversion of 3D bodies into beams and shell elements for finite element analysis (FEA) and the extraction of internal and external fluid volumes for CFD. Besides, additional geometries can be created very quickly and Spaceclaim has great tools that are geared towards preparing geometry to be ready for finite element analysis (FEA) and computational fluid dynamics (CFD) simulations.
All of this makes easy to find and remove parts that are not needed for further simulation. SpaceClaim includes many automated tools that identify faulty interfaces, and the software also has intelligent research. With SpaceClaim, you can easily review and clean up geometry and remove unnecessary elements without affecting relationships between existing parameters.
In a typically service-based CAD format, there are parametric histories which are based on dependency relationships - these often cause problems in CAD if we accidentally remove surfaces or parts that other elements rely on. Why is it important to clean CAD files, and what exactly does it mean?Įngineers often make simplistic changes in their models they often distort and deform them for simulation purposes – removing small details or edges of the models. Ansys SpaceClaim modeling software allows you to quickly create and modify geometries designs can be optimized for simulation or any other manufacturing method. One of the main strengths of SpaceClaim software is its speed and the fact that it can be used to work with CAD files imported from any source – it “cleans” these files faster than if it was done in a traditional CAD software. We will take a closer look at how Ansys SpaceClaim software works and explain why it makes easier for engineers to prepare simulations on a daily basis. SpaceClaim, a market leader in engineering simulation software, is part of the American Ansys product family, providing an efficient solution for a variety of simulation calculations for engineers in every industry. SpaceClaim – Have you heard of this CAD (computer aided design) simulation preparation software? This fast, easy-to-use, and innovative software is gaining increasing focus not only in America, but already in Western Europe and even in Australia.
